Name: Secondary

Display Field: Name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: ElecSecConductor SEC

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 5000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 976425.8916952014
YMin: 406126.7930471301
XMax: 1020995.6221651435
YMax: 427234.02609428763
Spatial Reference: 102748  (2285)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: OhUg
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: O/H
  Label: O/H
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [230, 152, 0, 255]
  Width: 1
• Value: U/G
  Label: U/G
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [169, 0, 230, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• AssetID ( type: esriFieldTypeString, alias: AssetID, length: 20 )
• AdministrativeArea ( type: esriFieldTypeString, alias: Administration, length: 16 )
• OperationalArea ( type: esriFieldTypeString, alias: Jurisdiction, length: 10 )
• Class ( type: esriFieldTypeString, alias: Class, length: 16 )
• Use_ ( type: esriFieldTypeString, alias: Use_, length: 20 )
• InstallDate ( type: esriFieldTypeDate, alias: InstallDate, length: 8 )
• AbandonDate ( type: esriFieldTypeDate, alias: AbandonDate, length: 8 )
• InspectDate ( type: esriFieldTypeDate, alias: InspectDate, length: 8 )
• Condition ( type: esriFieldTypeInteger, alias: Condition )
• LifeCycleStatus ( type: esriFieldTypeString, alias: Status, length: 20 )
• SubType ( type: esriFieldTypeInteger, alias: SubType )
• OhUg ( type: esriFieldTypeString, alias: OhUg, length: 4 )
• State ( type: esriFieldTypeString, alias: State, length: 16 )
• ConSz ( type: esriFieldTypeString, alias: ConSz, length: 12 )
• ConMtrl ( type: esriFieldTypeString, alias: ConMtrl, length: 12 )
• Config ( type: esriFieldTypeString, alias: Config, length: 4 )
• WireCount ( type: esriFieldTypeInteger, alias: WireCount )
• Phase ( type: esriFieldTypeString, alias: Phase, length: 12 )
• Phasing ( type: esriFieldTypeString, alias: Phasing, length: 15 )
• SubSta ( type: esriFieldTypeString, alias: SubSta, length: 24 )
• FeederNo ( type: esriFieldTypeString, alias: FeederNo, length: 16 )
• FeederPg ( type: esriFieldTypeString, alias: FeederPg, length: 55 )
• SectId ( type: esriFieldTypeString, alias: SectId, length: 12 )
• SectIdBack ( type: esriFieldTypeString, alias: SectIdBack, length: 12 )
• TagNo ( type: esriFieldTypeString, alias: TagNo, length: 50 )
• Notes ( type: esriFieldTypeString, alias: Notes, length: 255 )
• Name ( type: esriFieldTypeString, alias: Name, length: 60 )
• Project ( type: esriFieldTypeString, alias: Project, length: 255 )
• PrimaryImage ( type: esriFieldTypeString, alias: PrimaryImage, length: 250 )
• Grid ( type: esriFieldTypeString, alias: Grid, length: 4 )
• Location ( type: esriFieldTypeString, alias: Location, length: 100 )
• Street ( type: esriFieldTypeString, alias: Street, length: 50 )
• Str_Direction ( type: esriFieldTypeString, alias: Str_Direction, length: 2 )
• NE_XStreet ( type: esriFieldTypeString, alias: NE_XStreet, length: 50 )
• SW_XStreet ( type: esriFieldTypeString, alias: SW_XStreet, length: 50 )
• ArchiveNotes ( type: esriFieldTypeString, alias: ArchiveNotes, length: 255 )
• Enabled ( type: esriFieldTypeSmallInteger, alias: Enabled )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• Voltage ( type: esriFieldTypeDouble, alias: Voltage )
• Situs ( type: esriFieldTypeString, alias: Situs, length: 120 )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Relationships:

• WSketchLink (32) -- Related To: WSketch link (105)
• ScanData (33) -- Related To: ScanData (106)

Supported Operations:   Query   Query Related Records   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
